    Roller Conveyor

    Roller Conveyor

    | Gravity, Powered & Chain-Driven Conveyor

    Efficient, Flexible & Low-Maintenance Unit Load Handling

    Orchid’s Roller Conveyors include Gravity, Powered, and Chain-driven models. Efficient, low-maintenance unit load handling for logistics, packaging, food, pharma, automotive & industrial applications.

    Also known as Gravity Roller Conveyors, Powered Roller Conveyors, or Chain-Driven Roller Conveyors, these systems move cartons, boxes, bags, and unit loads safely and efficiently.

    How It Works

    •  Loading:Products are placed onto the rollers manually or via feeders.
    •  Material Movement:
    • Gravity Roller Conveyors → materials move freely by gravity or manual push.
    • Powered Roller Conveyors → rollers driven by motors, belts, or chains for controlled conveying.
    •  Discharge:Materials move smoothly to the end point or into downstream packaging/equipment.

    👉 Ensures smooth, flexible, and low-maintenance conveying of unit loads.

    Key Features

    •  Available in Gravity, Powered, and Chain-driven designs
    •  Handles cartons, bags, boxes, pallets, and unit loads
    •  Modular design → easy to install and expand
    •  Roller material options: MS, SS304, SS316, PVC-coated
    •  Frame construction: MS powder-coated / stainless steel
    •  Low noise and minimal maintenance
    •  Suitable for both manual and automated handling systems

    Applications

    •  Logistics & Warehousing:cartons, boxes, packaging lines
    •  Food & Pharma:containers, bottles, packaged items
    •  Automotive:parts, pallets, heavy components
    •  Chemicals & Plastics:drums, bags, bulk containers
    •  E-commerce & Retail:sortation, packaging, dispatch lines

    Benefits

    •  Cost-effective and durable solution
    •  Flexible design → horizontal, inclined, or curved layouts
    •  Reduces manual handling → safer operations
    •  Easy to integrate with scanners, sorters, and packaging systems
    •  Long service life with low maintenance

    Technical Highlights

    •  Capacity: 10 – 200 kg per roller (custom options available)
    •  Roller Diameter: 38 – 76 mm
    •  Roller Pitch: 75 – 150 mm
    •  Conveying Length: Up to 30 m per section
    •  Material of Construction: MS, SS304, SS316L
    •  Drive Options (powered): Motorized rollers, chain drive, belt drive
    •  Special Options: Curved roller conveyors, telescopic versions, mobile frames
    Download Brochure Download Brochure

    ❓ Final FAQ – Roller Conveyor

    • 1. What is a Roller Conveyor?

      👉 It is a conveying system consisting of rollers mounted on a frame, used to move cartons, boxes, and unit loads efficiently.

    • 2. What are the types of Roller Conveyors?
      • Gravity Roller Conveyor → economical, uses gravity/manual push
      • Powered Roller Conveyor → rollers driven by motors/belts
      • Chain-Driven Roller Conveyor → heavy-duty, for pallets & industrial loads
    • 3. Can Roller Conveyors be customized?

      Yes, they can be designed for different roller diameters, load capacities, frame lengths, and layouts.

    • 4. Which industries use Roller Conveyors?

      Warehousing, logistics, packaging, food, pharma, chemicals, automotive, and e-commerce.

    • 5. Do you provide stainless steel versions?

      Yes, SS304 and SS316L roller conveyors are available for hygienic industries.

    • 6. Note

      👉 Orchid’s Roller Conveyors — engineered for efficient, flexible, and low-maintenance unit load handling across industries.
